Description

Water Fire Extinguishers are suitable for class A fires caused by the combustion of solid materials, mainly of organic origin, such as: wood, paper, straw, textiles, coal etc.
Not for use on electrical equipment or electrical fires.

Specifications
Height 580mm
Diameter 175mm
Mass Empty 3.9kg
Mass Full 12.9kg
Discharge >12sec
Effective Range 3-12m
Discharge Nozzle Hose & Horn
Working Temperature -15/+60?C
Working Pressure 1400kPa
Test Pressure >2100kPa
Burst Pressure >5500kPa
Safety Device ?2200kPa
Neck Ring Thread M30 x 1.5
Pressure Indicator ?23 M10 x 1.0
Outlet Thread G ?” x 19
Syphon Tube M16 x 1.5
Specifications
Construction Deep draw type mild steel cylinder. (Welded neck and base) Valve
Brass Spec CZ 122 Die Forging Brass (HPB59-1)
Body Forged & Nickel plated
Discharge Hose Hose EN694 PVC 545mm & 580mm overall length
Cylinder Finish Red epoxy powder coated
Inner Lining PPA coated
